5
catalog lenses in the prototype design
Imaging lens for a 4K otoscope
Medical imaging device developer
2025
- Imaging
- Lens design
- Stray light
Work
Portfolio
Imaging lens design, illumination design, and methods. Client names are withheld.
Services lists the work behind these studies.
9 projects
~100x
worst-case contrast under sub-millimeter phone misalignment
Placement-tolerant optics for a smartphone dermatoscope
Medical device startup (digital dermatology)
2026
- Imaging
- Optomechanics
- Simulation
30+
automated validation gates
Image quality and detection toolkit for space optics
Space technology company
2026
- Imaging
- Simulation
- Automation
~90%
theoretical efficiency of the narrow beam
Beam-angle lens family for a clustered LED downlight
Architectural lighting manufacturer
2018
- Illumination
- Lens design
25% to 90%
optical efficiency into the detection area
Laser light delivery for a diagnostic test cartridge
Point-of-care diagnostics company
2025
- Illumination
- Lightguides
- Simulation
~5% to ~40%
coupling efficiency by resizing the fiber instead of adding optics
LED-to-fiber coupling feasibility study
Optical sensing instrument startup
2025
- Illumination
- Freeform
- Fiber optics
~450
two-bounce ghost paths matched to OpticStudio on every design
Independent check of ghost-path enumeration on 10 lens designs
Simulation, stray light (method study)
2026
- Simulation
- Stray light
5
benchmark tasks delivered and accepted
Engineering benchmark tasks for evaluating AI models
AI engineering-tools startup
2026
- AI/ML
- Optomechanics
- Simulation
~6%
of launched light lost under default ray-trace limits
Energy audit of a side-glowing fiber model
Simulation, fiber optics
2026
- Simulation
- Fiber optics
Discuss a similar system
Write with the wavelength band, the source or detector, and the decision you need.
Fixed-fee projects. Scope, deliverables, and price are agreed in writing before work starts.
Or write directly to hello@formlightoptics.com.
